About CREODIAS Datacubes

Copernicus Sentinel Satellite Datacubes

As a proud member of the EarthServer federation and the EOSC-hub initiative of the European Open Science Cloud, rasdaman contributes flexible, scalable datacubes on the CREODIAS Sentinel archive as part of Task 7.7 EO Pillar led by the European Space Agency. On the side, rasdaman stands out in EOSC-hub as one of the few SMEs participating in a collaboration with large-scale public data centers.

The rasdaman Datacube Engine

The rasdaman datacube engine has pioneered actionable datacubes by establishing an array query language, meantime adopted as an ISO SQL extension standard, and a massively scalable distributed array database system. The technological lead of rasdaman is proven by multi-Petabyte operational services, open benchmarks, and a continuous series of international innovation awards. While in EOSC-hub Earth Observation datacubes are provided, rasdaman is domain-independent and has proven advantageous on human brain images, genetics, astrophysics, and other EOSC domains.

The EOSC-hub project

EU H2020 EOSC-hub is a lead contributor to the development of EOSC. EOSC-hub brings together multiple service providers to create the Hub: a single contact point for European researchers and innovators to discover, access, use and reuse a broad spectrum of resources for advanced data-driven research. For researchers, this will mean a broader access to services supporting their scientific discovery and collaboration across disciplinary and geographical boundaries. The project mobilises providers from the EGI Federation, EUDAT CDI, INDIGO-DataCloud and other major European research infrastructures to deliver a common catalogue of research data, services and software for research.

Explore the Actionable Datacubes

Data Available


Quick links: [ Sentinel-2 | Landsat-5 | Landsat-7 | Landsat-8 ]

Sentinel-2

  • MSI

    • L1C

      Temporal extent: 2018/11 - 2018/12
      Spatial extent: Europe (UTM 32601 - 32660)
      Resolution: 10m, 20m or 60m
      Naming scheme: Sentinel2_MSI_L1C_${missionId}_${band}_${utmCrsCode}
      ${missionId} - S2A or S2B
      ${band} - B01, B02, B03, B04, B05, B06, B07, B08, B09, B10, B11, B12, B8A and TCI
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660

    • L1C - projected to global WGS84 CRS coverages

      • Spatial extent: Global (EPSG:4326)
      • Coverage: Europe_Sentinel2_L1C_10m

        Temporal extent: 2018-06-01 - 2018-06-06
        Spatial extent: Europe
        Resolution: 10m in UTM CRS before projection to EPSG:4326
        Bands: B02, B03, B04 and B08

      • Coverage: Europe_Sentinel2_L1C_20m

        Temporal extent: 2018-06-01 - 2018-06-06
        Spatial extent: Europe
        Resolution: 20m in UTM CRS before projection to EPSG:4326
        Bands: B05, B06, B07, B8A, B11 and B12

      • Coverage: Europe_Sentinel2_L1C_60m

        Temporal extent: 2018-06-01 - 2018-06-06
        Spatial extent: Europe
        Resolution: 60m in UTM CRS before projection to EPSG:4326
        Bands: B01, B09, B10

      • Coverage: Global_Sentinel2_L1C_TCI

        Temporal extent: 2018-06-15 - 2018-06-30
        Spatial extent: World
        Resolution: 60m in UTM CRS before projection to EPSG:4326
        Bands: red, green and blue (TCI)

Landsat-5

  • TM

    • L1G

      Temporal extent: 2011
      Spatial extent: Europe (UTM 32629 - 32645)
      Resolution: 30m
      Naming scheme: Landsat5_TM_L1G_${product}_${band}_${utmCrsCode}
      ${product} - RMPS, RKSE, RMTI and RFUI
      ${band} - B1, B2, B3, B4, B5, B6 and B7
      ${utmCrsCode} - EPSG code for datacube CRS: 32629 - 32645 (N)

    • L1T

      Temporal extent: 2011
      Spatial extent: Europe (UTM 32629 - 32645)
      Resolution: 30m
      Naming scheme: Landsat5_TM_L1T_${product}_${band}_${utmCrsCode}
      ${product} - RMPS, RKSE, RMTI and RFUI
      ${band} - B1, B2, B3, B4, B5, B6 and B7
      ${utmCrsCode} - EPSG code for datacube CRS: 32629 - 32645 (N)

Landsat-7

  • ETM

    • GTC_1P

      Temporal extent: 2003
      Spatial extent: Europe (UTM 32625 - 32637)
      Resolution: 30m
      Naming scheme: Landsat7_ETM_GTC_1P_${product}_${band}_${utmCrsCode}
      ${product} - RMPS, RKSE, RMTI and RFUI
      ${band} - B1, B2, B3, B4, B5, B6_VCID_1, B6_VCID_2, B7 and B8
      ${utmCrsCode} - EPSG code for datacube CRS: 32625 - 32637 (N)

    • L1G

      Temporal extent: 2002 - 2015
      Spatial extent: World (UTM 32601 - 32660)
      Resolution: 30m
      Naming scheme: Landsat7_ETM_L1G_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6_VCID_1, B6_VCID_2, B7 and B8
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660 (N)

    • L1GT

      Temporal extent: 1999 - 2013
      Spatial extent: World (UTM 32601 - 32660)
      Resolution: 30m
      Naming scheme: Landsat7_ETM_L1GT_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6_VCID_1, B6_VCID_2, B7 and B8
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660 (N)

    • L1T

      Temporal extent: 2000 - 2017
      Spatial extent: World (UTM 32601 - 32660)
      Resolution: 30m
      Naming scheme: Landsat7_ETM_L1GT_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6_VCID_1, B6_VCID_2, B7 and B8
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660 (N)

Landsat-8

  • OLI

    • L1GT

      Temporal extent: 2013 - 2018
      Spatial extent: Europe (UTM 32627 - 32644)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_L1GT_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32627 - 32644 (N)

    • L1T

      Temporal extent: 2013 - 2017
      Spatial extent: Europe (UTM 32629 - 32642)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_L1T_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32629 - 32642 (N)

    • L1TP

      Temporal extent: 2018
      Spatial extent: Europe (UTM 32629 - 32639)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_L1TP_${product}_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32629 - 32639 (N)

  • OLI_TIRS

    • L1GT

      Temporal extent: 2018
      Spatial extent: Europe (UTM 32601 - 32647)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_TIRS_L1GT_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9, B10, B11 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32647 (N)

    • L1T

      Temporal extent: 2017
      Spatial extent: Europe (UTM 32601 - 32660)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_TIRS_L1T_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9, B10, B11 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660 (N)

    • L1TP

      Temporal extent: 2018
      Spatial extent: Europe (UTM 32629 - 32639)
      Resolution: 30m
      Naming scheme: Landsat8_OLI_TIRS_L1TP_${product}_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9, B10, B11 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32660 (N)

  • TIRS

    • L1GT

      Temporal extent: 2018
      Spatial extent: Europe (UTM 32601 - 32647)
      Resolution: 30m
      Naming scheme: Landsat8_TIRS_L1GT_${band}_${utmCrsCode}
      ${band} - B1, B2, B3, B4, B5, B6, B7, B8, B9, B10, B11 and BQA
      ${utmCrsCode} - EPSG code for datacube CRS: 32601 - 32647 (N)
